C24 Series Motor Controller
High-current compact FOC controller with 36–88 V input
Overview
The C24 Series is a compact, non-isolated sinusoidal motor controller built on our proprietary FOC algorithm, with rated input currents up to 95 A in three model variants. It delivers smooth torque control for PMSM, SynRM and induction motors in an IP66-rated housing.
- FOC / MTPA / SVPWM with flux weakening
- Efficiency up to 97%
- IP66 protection rating
- Non-Isolated Type
- Built-in 6-Axis Sensor Optional
- Built-in Bluetooth Optional
Technical Specifications
| Parameter | DEMCC2400/2401 | DEMCC2410/2411 | DEMCC2420/2421 | ||
|---|---|---|---|---|---|
| Rated Input Voltage (DC-V) | 36~72 | ||||
| Rated Input Current (DC-A) | 70 | 80 | 95 | ||
| Rated Output Current (Arms@30min) | 70 | 80 | 95 | ||
| Input Voltage Range (DC-V) | 36~88 | ||||
| Maximum Input Current (DC-A, 10s) | 150 | 200 | 300 | ||
| Maximum Output Current (Apk@3s) | 410 | 510 | 660 | ||
| Operating Ambient Temperature (℃) | -20~+65 | ||||
| Motor Type | PMSM / SynRM / Induction Motor | ||||
| Motor Control Method | FOC/MTPA/SVPWM/Flux Weakening | ||||
| Motor Sensor Type | SinCos / ABZ(+PWM) / HALL ABC (select one of three) | ||||
| Efficiency | 97% | ||||
| Protection | OverCurrent / OverVoltage / OverTemperature / Stall | ||||
| Dimensions (mm) | 187*111*55 | ||||
| Weight (kg) | <1.2 | ||||
| Communication | CAN2.0 / 1-Wire / 485 | ||||
| Cooling Method | Forced Air Cooling | ||||
| Protection Rating | IP66 | ||||
Frequently Asked Questions
What is the maximum efficiency of this controller?
The controller achieves an efficiency of up to 97% using advanced FOC algorithms.
What is the input voltage range supported?
It supports a wide input voltage range from 36V to 88V DC.
Does the controller support motor customization?
Yes, full customization, minor customization, and customization from designs or samples are available.
Is the controller suitable for outdoor use?
Yes, it features an IP66 protection rating, making it suitable for harsh and outdoor environments.
Can the software be customized?
Yes, the software can be customized to meet the different requirements of individual customers.
What communication protocols are supported?
It supports CAN 2.0, 1-Wire, and 485 communication protocols.
